| Items | Specifications |
| Lithium-ion/Lithium Polymer | LiFePO4 |
| Charge | Charging voltage(CC/CV)-10S | CC/CV:42V | CC/CV:36V |
| Charging voltage(CC/CV)-13S | CC/CV:54.6V | CC/CV:46.8V |
| Maximal continuous charging current | 5a(Max) |
| Discharge | Maximal continuous discharging current | 20a(Max) |
| Low current consumption | Current consumption on operation | <20μA |
| Current consumption at power down | <0.1μA |
| Cell-balance | Cell-balance detection voltage | 4.20 ± 0.03 V | 3.60 ± 0.03 V |
| Cell-balance release voltage | 4.20 ± 0.03 V | 3.60 ± 0.03 V |
| Cell-balance current | 68 ±3mA | 58 ±3mA |
| Over-charge | Overcharge detection voltage | 4.25±0.025V | 3.900 ± 0.025V |
| Overcharge release voltage | 4.15±0.05V | 3.800 ± 0.050V |
| Overcharge delay time | 0.5~2S |
| Over-discharge | Overdischarge detection voltage | 2.50±0.062V | 2.00±0.080V |
| Overdischarge release voltage | 3.0±0.075V | 2.30±0.100V |
| Overdischarge delay time | 100~250mS |
| Discharge overcurrent | Discharge overcurrent detection voltage | 0.2±0.015V | 0.10±0.015V |
| Discharge overcurrent delay time | 15~35ms |
| Discharge overcurrent protection | 50±10a(can adjust) |
| Release condition | Cut-off-load |
| Short-circuiting protection | Load short-circuiting detection voltage | / | / |
| Detection condition | Exterior short circuit |
| Load short-circuiting detection delay time | 200~800μs |
| Release condition | Cut-off-load |
| Internal resistance | Static Drain-Source On-Resistance | <40mΩ(B- to P-) |
| Temperature | Wide range of operation temperature | 40 ~ + 85ºC |
| Storage Temperature Range | -40 ~ +125ºC |
| Dimension | L82*W60*T12mm |
